Articulating Knuckle Boom Cranes for Sale and Rent
Articulating Knuckle Boom Cranes Specifications
Knuckle boom cranes (also known as articulating cranes) are more compact than conventional boom truck cranes, allowing for more flexibility and increased payload. For many jobs, the... Show More
Manufacturers
Sort By:
New Palfinger PK 5.501 SLD 5 For Sale
Location |
Houston, Texas US 1193 miles |
---|---|
Make | Palfinger |
Model | PK 5.501 SLD 5 |
Tons | 3.64 |
Year | 2024 |
Price On Request
FeaturesPalfinger PK 5.501 SLD 5 loader crane
Specs
- Max. lifting moment: 5.1 mt
- Max. lifting capacity: 3300 kg
- Max. hydraulic outreach: 11.1 m
- Max. manual outreach: 12.7 m
- Slewing angle: 400°
- Slewing torque: 0.6 mt
- Stabilizer spread (std): 2.9 m
- Fitting space required (std): 0.66 m
- Width folded: 2.10 m
- Max. operating pressure: 360 bar
- Pump capacity: 20 - 30 l/min
- Dead weight (std): 750 kg
Used 2016 Palfinger PK 33002 EH on Used 2016 Kenworth T800 For Sale
Location |
San Marcos, California US 2234 miles |
---|---|
Make | Palfinger |
Model | PK 33002 EH |
Tons | 11.02 |
Year | 2016 |
Price On Request
FeaturesPalfinger PK 33002 EH knuckle boom crane
STANDARD FEATURES
- Maximum lifting moment 31.1 mt (224,940 ft-lbs).
- Paltronic 50 Overload Protection System.
- Outer boom tilts 15° above horizontal (Power Link Plus).
- Rotation angle 400°.
- Outriggers hydraulically ext. 21' 8" (R3X)
- Fixed hyd. stabilizers (STZS) with LED lighting.
- 4-function Danfoss control valve.
- Radio remote control with Paltronic 50 display on handset, prepared for 6-functions.
- Single ground control station with LED lighting.
- No spare control valve sections.
- Bubble level at both outrigger control stations.
- Provision for lifting capacity limitation dependent on rotation angle (SHB01).
- Load holding valves...
2020 Heila-Kenworth HLR 70000-3S KnuckleBoom Crane; CranesList ID: 869 For Sale
Location |
North Carolina US 243 miles |
---|---|
Make | Heila |
Model | HLR 70000-3S |
Tons | 30.00 |
Year | 2020 |
Price On Request
by CranesList
2020 Heila-Kenworth, HLR70000-3S, 30 Ton, KnuckleBoom Crane; CranesList ID: 869,
28′ Three Hydraulic Articulating Boom Sections,
Horizontal Cap: 60,000 lb @ 8′, 37,000 lb @ 13.5′, 7,500 lb @ 18.5′, 20,000 lb @ 23′, 14,300 lb @ 28′
DANFOSS Proportional Valve Controls – Single Sided Operator Control Station
SCANRECO Wireless Radio Remote Included,
Centered Knuckle with No Offset,
Dual Main Lift Cylinders and Dual Extension Cylinders,
Planetary Pedestal – Continuous Boom Rotation,
Load Holding Valves on All Cylinders,
2 Batteries for Remote + 50′ Backup Cord,
Rear Mounted behind the cab of...
2018 Effer 655 6S Articulating Knuckle Boom Crane For Sale or Rent
Location |
Easton, Massachusetts US 394 miles |
---|---|
Make | Effer |
Model | 655 6S |
Year | 2018 |
Price On Request
One (1) Used 2018 Effer Model 655/6S, S/N: 100027551, Articulating Crane
Crane Specifications
- 6 Section Boom Max: 6,040 Lbs at 56.1 Feet
- 6 Section HD Jib Max 1,521 Lbs at 98.72 Feet
- Hydraulic Out and Down Outriggers
- Remote Control
- Continuous Rotation
- Hydraulic Oil Cooler
- GMT 040 Grapple Saw
- Grapple Rotator
Mounted on (1) Used 2019 Western Star 4700
- Detroit Diesel
- Allison Automatic
- 18,000 Lbs Front Axle Rating
- 11,020 Lbs Pusher Axle Rating
- 40,000 Lbs Rear Axle Rating
- Diff Locks Both Rear Axles
- Custom Aluminum Truck Body
- Pintle Hitch
- Engine Hours: 1,476 (as of 1/11/24
- ...
Used 2016 Palfinger PK 7.001 Knuckle Boom Crane For Sale
Location |
Los Angeles, California US 2270 miles |
---|---|
Make | Palfinger |
Model | PK 7.001 SLD 1 |
Year | 2021 |
$84,999 USD
by yellowsack
Price is negotiable
Used 2021 IMT 12/86SL K3 Knuckle Boom Crane For Sale
Location |
San Francisco, California US 2410 miles |
---|---|
Make | IMT |
Model | 12/86SL K3 |
Tons | 3.02 |
Year | 2021 |
$129,999 USD
by yellowsack
Price is negotiable
New IMT 810RC K3 For Sale
Location |
Brighton, Colorado US 1457 miles |
---|---|
Make | IMT |
Model | 810 RC K3 |
Tons | 4.12 |
Year | 2023 |
Price On Request
FeaturesPower up your productivity with IMT® articulating cranes. With a superior lift-to-weight ratio and industry-leading reach, IMT articulating cranes offer the performance, versatility, and dependability you need to enhance efficiency and productivity — even on the most challenging job sites.
Standard features:
- Application-specific product offering
- Superior lift-to-weight ratio
- Long-reach capabilities
- Hexagonal booms for superior reach and maximum control
- Internal hose routing
- 15° overbending on outer boom
New IMT 40/275 K5 FJ1000 K3 on New Kenworth T880 For Sale
Location |
Houston, Texas US 1193 miles |
---|---|
Make | IMT |
Model | 40/275 K5 FJ1000 K3 |
Tons | 9.51 |
Year | 2023 |
Price On Request
FeaturesIMT 40/275 K5 FJ1000 K3 knuckle boom crane
Bring power, durability, and proven performance to your job site with IMT® 40/275 articulating cranes. With a max lifting capacity of 19,025 lb (8,630 kg), as well as a horizontal reach of 69 ft 11 in (21.3 m), these compact cranes deliver heavy-duty lifting and long-reach capabilities for any number of challenging tasks. Plus, their unique hexagonal booms offer strength and stability, and the thoughtful innovations to make your job easier.
Standard features
- Application-specific product offering
- Superior lift-to-weight ratio
- Long-reach capabilities
- Hexagonal booms for superior reach and maximum control
New IMT 40/275 K5 FJ1000 K3 For Sale
Location |
Houston, Texas US 1193 miles |
---|---|
Make | IMT |
Model | 40/275 K5 FJ1000 K3 |
Tons | 9.51 |
Year | 2023 |
Price On Request
FeaturesIMT 40/275 K5 FJ1000 K3 knuckle boom crane
Bring power, durability, and proven performance to your job site with IMT® 40/275 articulating cranes. With a max lifting capacity of 19,025 lb (8,630 kg), as well as a horizontal reach of 69 ft 11 in (21.3 m), these compact cranes deliver heavy-duty lifting and long-reach capabilities for any number of challenging tasks. Plus, their unique hexagonal booms offer strength and stability, and the thoughtful innovations to make your job easier.
Standard features
- Application-specific product offering
- Superior lift-to-weight ratio
- Long-reach capabilities
- Hexagonal booms for superior reach and maximum control
New IMT 810RC K4 on New Ford F-600 For Sale
Location |
Brighton, Colorado US 1457 miles |
---|---|
Make | IMT |
Model | 810 RC K4 |
Tons | 4.12 |
Year | 2023 |
Price On Request
New IMT 810RC K4 For Sale
Location |
Houston, Texas US 1193 miles |
---|---|
Make | IMT |
Model | 810 RC K4 |
Tons | 4.12 |
Year | 2023 |
Price On Request
Used 2015 Fassi F385A.2.26 L212 on Used 2015 Western Star 4700SB For Sale
Location |
Olathe, Kansas US 932 miles |
---|---|
Make | Fassi |
Model | F385A.2.26/L212 |
Tons | 13.23 |
Year | 2015 |
$179,850 USD
FeaturesFassi F385A.2.26 L212 knuckle boom crane
- LIFTING CAPACITY: Up to 245,488lbs.ft
- MAX OUTREACH: Up to 74'5"” with jib
- OVERALL DIMENSIONS: 4’4” ft length, 8’3” ft width, 7’11”ft height
ELECTRONIC/HYDRAULIC EQUIPMENT:
- FX800 control unit
- D850 digital distributor bank
- RCH/RCS radio remote control unit
- ADC automatic dynamic control flow sharing
CHARACTERISTICS:
- Dynamic version (.2): with linkage
- Prolink system with double linkage rotation
- 430° with rack and pinion
2021 BIK TC-106 Knuckle Boom Crane For Sale
Location |
New Boston, New Hampshire US 405 miles |
---|---|
Make | BIK |
Model | TC-106 |
Tons | 65.00 |
Year | 2021 |
$455,000 USD
New Cormach 240000X E9 J404 HP RC TI A.S.C. Plus For Sale
Location |
Houston, Texas US 1193 miles |
---|---|
Make | Cormach |
Model | 240000AX E9J404 |
Tons | 34.45 |
Year | 2025 |
Price On Request
FeaturesTechnical Specifications:
Static moment at the turret pin: 229500 (daN/m), 1660295 (lbs/ft)
Hyd. boom length: 147' 5" (in)
Length: 9560 (mm), 31' 4" (in)
Width: 2540 (mm), 8' 4" (in)
Height: 2870 (mm), 9' 4" (in)
Weight (without oil and fitting): 28250 (kg), 62281 (lbs)
Slew torque: 22000 (daN/m), 159157 (lbs/ft)
Outriggers extension: 5850 + 5850 (mm), 19' 2" + 19' 2" (in)
Outriggers width: 11972 (mm), 39' 3" (in)
Pump delivery: 115 (lit/min), 30 (gal/min)
Pressure: 320 (bar), 4550 (Psi)
Oil tank capacity: 650 (lit), 169 (us gal)
Used 2020 IMT 50/345 K5 on New Kenworth T880 For Sale
Location |
Houston, Texas US 1193 miles |
---|---|
Make | IMT |
Model | 50/345 K5 |
Tons | 10.48 |
Year | 2020 |
Price On Request
FeaturesIMT® 50/345 articulating cranes feature hexagonal booms for greater strength and stability while providing a maximum horizontal boom reach of 70 ft (21.4 m) and a max lifting capacity of 22,840 lb (10,360 kg). That’s a lot of lifting power for articulating cranes that require minimal mounting space and offer the versatility to maneuver around difficult job sites.
Standard features:
Application-specific product offering
Superior lift-to-weight ratio
Long-reach capabilities
Hexagonal booms for superior reach and maximum control
Options:
Various stabilizer configurations
Double link arm system
Boom mounted winch
Floodlight on outer boom
Boom tip functions for hydraulic attachments
Oil...
New Cormach 51800 E3 A.S.C Plus For Sale
Location |
Houston, Texas US 1193 miles |
---|---|
Make | Cormach |
Model | 51800 E3 CW ASC PLUS |
Year | 2024 |
Price On Request
New Cormach 51800 E3 A.S.C Plus For Sale
Location |
Houston, Texas US 1193 miles |
---|---|
Make | Cormach |
Model | 51800 E3 CW ASC PLUS |
Year | 2024 |
Price On Request
New Cormach 51800 E3 A.S.C Plus For Sale
Location |
Houston, Texas US 1193 miles |
---|---|
Make | Cormach |
Model | 51800 E3 CW ASC PLUS |
Year | 2024 |
Price On Request
New Cormach 51800 E3 A.S.C Plus For Sale
Location |
Houston, Texas US 1193 miles |
---|---|
Make | Cormach |
Model | 51800 E3 CW ASC PLUS |
Year | 2024 |
Price On Request
New IMT 32/222 K4 For Sale
Location |
Olathe, Kansas US 932 miles |
---|---|
Make | IMT |
Model | 32/222 K4 |
Tons | 6.32 |
Year | 2023 |
Price On Request
FeaturesPower up your productivity with the IMT® 32/222 articulating crane. Featuring a superior lift-to-weight ratio, our 32/222 model has a maximum lift capacity of 15,058 pounds (6830 kg) and one of the industry’s longest maximum horizontal reaches in the 30 tm range: 69 feet 7 inches (21.2 meters). This crane offers the performance, versatility and dependability you need to enhance efficiency — even on the most challenging jobsites.
Standard features:
Application-specific product offering
Superior lift-to-weight ratio
Long-reach capabilities
Hexagonal booms for superior reach and maximum control
Internal hose routing
15° overbending on outer boom
Options:
Various stabilizer configurations...
New IMT 32/222 K4 on New Kenworth T880 For Sale
Location |
Houston, Texas US 1193 miles |
---|---|
Make | IMT |
Model | 32/222 K4 |
Tons | 6.32 |
Year | 2023 |
Price On Request
FeaturesPower up your productivity with the IMT® 32/222 articulating crane. Featuring a superior lift-to-weight ratio, our 32/222 model has a maximum lift capacity of 15,058 pounds (6830 kg) and one of the industry’s longest maximum horizontal reaches in the 30 tm range: 69 feet 7 inches (21.2 meters). This crane offers the performance, versatility and dependability you need to enhance efficiency — even on the most challenging jobsites.
Standard features:
Application-specific product offering
Superior lift-to-weight ratio
Long-reach capabilities
Hexagonal booms for superior reach and maximum control
Internal hose routing
15° overbending on outer boom
Options:
Various stabilizer configurations...
New IMT 32/222 K4 For Sale
Location |
Houston, Texas US 1193 miles |
---|---|
Make | IMT |
Model | 32/222 K4 |
Tons | 6.32 |
Year | 2023 |
Price On Request
FeaturesPower up your productivity with the IMT® 32/222 articulating crane. Featuring a superior lift-to-weight ratio, our 32/222 model has a maximum lift capacity of 15,058 pounds (6830 kg) and one of the industry’s longest maximum horizontal reaches in the 30 tm range: 69 feet 7 inches (21.2 meters). This crane offers the performance, versatility and dependability you need to enhance efficiency — even on the most challenging jobsites.
Standard features:
Application-specific product offering
Superior lift-to-weight ratio
Long-reach capabilities
Hexagonal booms for superior reach and maximum control
Internal hose routing
15° overbending on outer boom
Options:
Various stabilizer configurations...
New Fassi F2150RAL.2.28 xhe-dynamic For Sale
Location |
Houston, Texas US 1193 miles |
---|---|
Make | Fassi |
Model | F2150RAL.2.28 |
Tons | 31.60 |
Year | 2024 |
Price On Request
FeaturesLIFTING CLASS:
Highest moment 160 tm / 1570 kNm
MAX OUTREACH:
up to 41,30 m with jib
OVERALL DIMENSIONS:
from: w 4,18 m , l 2,54 m , h 2,73
ELECTRONIC/HYDRAULIC EQUIPMENT:
IMC integral machine control
FX900 control unit
D900 double digital distributor bank
RCH/RCS radio remote control unit
ADC automatic dynamic control
FX901 - touch screen display
flow sharing
CHARACTERISTICS:
dynamic version (.2): with linkage
XP device
Prolink system with double linkage
continuous rotation on a slew ring with double motoreducer
double hydraulics circuit
New Fassi F145AZ.0.22 For Sale
Location |
Olathe, Kansas US 932 miles |
---|---|
Make | Fassi |
Model | F145AZ.0.22 |
Tons | 3.08 |
Year | 2023 |
Price On Request
FeaturesF145AZ Fassi knuckle boom crane
Available grapple attachment
LIFTING CAPACITY:
up to 14 tm
MAX OUTREACH:
up to 8,25 m
OVERALL DIMENSIONS:
from: w. 2,50 m, l. 0,75 m, h. 2,65 m
ELECTRONIC/HYDRAULIC EQUIPMENT:
Control unit FX500
Hydrocontrol HC/D4 segmented distributor bank
CHARACTERISTICS:
Active version (.0): without linkage
Rotation 415° with rack and pinion
New Fassi F145AZ.0.22 For Sale
Location |
Olathe, Kansas US 932 miles |
---|---|
Make | Fassi |
Model | F145AZ.0.22 |
Tons | 3.08 |
Year | 2023 |
Price On Request
FeaturesF145AZ Fassi knuckle boom crane
Available grapple attachment
LIFTING CAPACITY:
up to 14 tm
MAX OUTREACH:
up to 8,25 m
OVERALL DIMENSIONS:
from: w. 2,50 m, l. 0,75 m, h. 2,65 m
ELECTRONIC/HYDRAULIC EQUIPMENT:
Control unit FX500
Hydrocontrol HC/D4 segmented distributor bank
CHARACTERISTICS:
Active version (.0): without linkage
Rotation 415° with rack and pinion
Manufacturers
600SA (2)
ACE (Action Construction Equipment) (12)
Amco Veba (123)
Atlas (12)
Auto Crane (1)
BIK (4)
Copma (65)
Cormach (320)
Effer (870)
ACE (Action Construction Equipment) (12)
Amco Veba (123)
Atlas (12)
Auto Crane (1)
BIK (4)
Copma (65)
Cormach (320)
Effer (870)
Fassi (1353)
Ferrari (275)
HMF (54)
Heila (3)
Hiab (328)
Hidrokon (51)
Hyva (3)
IMT (353)
Ing. Bonfiglioli (52)
Ferrari (275)
HMF (54)
Heila (3)
Hiab (328)
Hidrokon (51)
Hyva (3)
IMT (353)
Ing. Bonfiglioli (52)
Knuckle boom cranes (also known as articulating cranes) are more compact than conventional boom truck cranes, allowing for more flexibility and increased payload. For many jobs, the flatbed truck that carries the crane can haul all materials and offload them at the job site, saving time and money.
The space efficiency of knuckle boom cranes also makes them highly versatile, with the ability to be cab-mounted, truck-mounted, tractor-mounted, or trailer-mounted.
BIK offers a wide range of articulating knuckle boom cranes from Heila, PM, and the BIK Series.
Crane Specifications, Load Charts, and Crane Manuals are for *Reference Only* and are not to be used by the crane operator to operate any type of crane, telehandler, lift truck or aerial access device. To obtain OEM Crane Service, Crane Parts or Crane Maintenance Manuals, contact the crane and or lifting manufacturer directly.
