Terex Girolift 5022 Specifications
The Terex Girolift 5022 is a rotating telehander manufactured from 2000-2007.
Dimensions
LENGTH TO FORK FACE
24.8 ft in
7550... Show More
Terex Girolift 5022
(Telehandlers, Forklifts & Lift Trucks : Telehandlers)
The Terex Girolift 5022 is a rotating telehander manufactured from 2000-2007.
|
Dimensions |
||
| LENGTH TO FORK FACE | 24.8 ft in | 7550 mm |
| WIDTH OVER TIRES | 8.2 ft in | 2490 mm |
| OVERALL HEIGHT | 10 ft in | 3050 mm |
| WHEELBASE | 11.5 ft in | 3500 mm |
| GROUND CLEARANCE | 16.9 ft in | 430 mm |
|
Lift |
||
| F. MAX LIFT HEIGHT | 70.9 ft in | 21625 mm |
| G. MAX FORWARD REACH | 62 ft in | 18900 mm |
Specifications
| Engine | ||
| GROSS POWER | 152 hp | 113.3 kw |
| POWER MEASURED @ | 2300 rpm | |
| NUMBER OF CYLINDERS | 6 | |
| ASPIRATION | turbocharged | |
| Operational | ||
| OPERATING WEIGHT | 39683.2 lb | 18000 kg |
| FUEL CAPACITY | 33 gal | 125 L |
| HYDRAULIC SYSTEM FLUID CAPACITY | 52.8 gal | 200 L |
| TIRE SIZE | 18/22.5'' PR 16 | |
| Transmission | ||
| TYPE | hydrostatic 2-speed mechanical gearbox | |
| MAX SPEED - FORWARD | 18.6 mph | 30 km/h |
| MAX SPEED - REVERSE | 18.6 mph | 30 km/h |
| Hydraulic | ||
| PUMP TYPE | variable displacement load sensing | |
| PUMP FLOW CAPACITY | 52.8 gal/min | 200 L/min |
| RELIEF VALVE PRESSURE | 3625.9 psi | 25000 kPa |
| Lift | ||
| MAX LIFT CAPACITY | 11023.1 lb | 5000 kg |
| MAX LIFT HEIGHT | 70.9 ft in | 21625 mm |
| MAX LOAD AT MAX HEIGHT | 5732 lb | 2600 kg |
| MAX FORWARD REACH | 62 ft in | 18900 mm |
| MAX LOAD AT MAX REACH | 881.8 lb | 400 kg |
| Dimensions | ||
| LENGTH TO FORK FACE | 24.8 ft in | 7550 mm |
| WIDTH OVER TIRES | 8.2 ft in | 2490 mm |
| OVERALL HEIGHT | 10 ft in | 3050 mm |
| WHEELBASE | 11.5 ft in | 3500 mm |
| GROUND CLEARANCE | 16.9 ft in | 430 mm |
| TURNING RADIUS OUTSIDE TIRES | 15.9 ft in | 4840 mm |
