Sany SCC8500 Specifications

The SANY SCC8500 lattice-boom crawler crane has a rated lift capacity of 550 tons and provides 10 configurations for main boom, fixed jib, and luffing jib. The maximum main-boom length is 345 feet for the basic machine and 394 feet for the optional UltraLift configuration.

The Auto Counterbalance Equalization (ACE) system senses boom angle and uses hydraulic cylinders to automatically adjust the position of the movable upper-works counterweight. A proprietary load-moment indicator detects lifting capacity, boom angle, tip height, and lift radius, and a closed-circuit television system provides in-cab views of all winches, counterweight, and operating areas.

The sleek cab, styled by the Porsche Design Studio, features a steel frame with added structural plated overhead, reinforced glass, and a heating and air-conditioning system powered by an auxiliary diesel generator.

Basic Crane Specifications:

• 550 Ton Capacity
• Cummins QSX 15 – 600 HP @ 1800 RPM
• Hydraulic System by Rexroth – Pumps & Drive Motors
• SANY Designed LMI Display Screen
• UltraCab Designed by Porsche Design Studios
• 10 Configurations Available for Main Boom, Fixed Jib & Luffing Jib

Standard Features:

• ACE System (Auto Counterbalance Equalization System)
• UltraLift Prep
• Auxiliary Generator
• Main Drum Ball Limits
• Main Drum & Rear Counterweight Camera System
• Basic Machine Lighting Package
• Aircraft Warning Light
