Grove RT865BXL Specifications
Grove RT865BXL
(Cranes, Hoists & Material Handlers : Rough Terrain Cranes)
No longer in production, the 65-ton USt Grove RT865BXL Rough Terrain Crane features the 35' - 138' (10.6 - 42 m) extra-long main boom for a maximum tip height of 204' (62.1 m) with the 31' -56' (9.4 - 17 m) bi-fold lattice swing-away jib extension.
CRANE SPECIFICATIONS
Main Telescopic Boom
|
Max Elevating Angle |
78 ° |
|
Max Height @ Max Raise Angle - no jib |
138' (42 m) |
|
Max Lift Capacity |
130, 000 lbs (58, 968 kg) |
|
Max Operating Radius |
120 ft (37 m) |
|
Min Height @ Max Raise Angle |
35 ft (11 m) |
|
Min Operating Radius |
10 ft (3 m) |
|
Number of Sections |
5 |
|
Swing Speed |
2 rpm |
Dimensions
|
Carrier/Base Length |
28.3 ft (9 m) |
|
Ground Clearance |
1.2 ft (0 m) |
|
Transport Height |
13.1 ft (4 m) |
|
Transport Length |
4.3 ft (1 m) |
|
Transport Width |
10.9 ft (3 m) |
|
Upper Structure Tail Swing Radius |
14.1 ft (4 m) |
|
Wheelbase |
13.4 in (34 cm) |
|
Width w/ Outriggers Extended |
26.6 ft (8 m) |
Engine
|
Aspiration |
turbocharged |
|
Displacement |
506.5 cu in (0 m) |
|
Engine Make |
Cummins |
|
Engine Model |
6CTA 8.3L |
|
Gross Power |
249.5 hp (186 kw) |
|
Max Torque |
794.4 lbs/ft |
|
Number of Cylinders |
6 |
|
Power Measured @ |
2200 rpm |
|
Torque Measured @ |
1500 rpm |
Operating Specifications
|
Fuel Capacity |
80.1 gal (303 l) |
|
Hydraulic System Fluid Capacity |
200 gal (757 l) |
|
Operating Voltage |
24 V V |
|
Operating Weight |
102841.3 lbs (46, 649 kg) |
|
Tire Size |
33.25X29-32PR |
Transmission
|
Max Speed - Forward |
24.9 mph (40 kph) |
|
Number of Forward Gears |
6 |
|
Number of Reverse Gears |
6 |
|
Transmission Type |
full powershift |
