XCMG QAY160 160-ton All Terrain Mobile Crane For Sale
Location: Xuzhou, Jiangsu, China Get a Shipping QuoteXCMG Authorized Dealer
| Status | For Sale |
|---|---|
| Year | 2020 |
| Manufacturer | XCMG |
| Model | QAY160 |
| Condition | Excellent |
| Ton (USt) | 175.00 |
| Lifting Capacity | 176,370 lbs. (160,000 kg) |
| Main Boom Length | 44.6' - 196.8' (13.6 - 60 m) |
| Max. Tip Height | 262.4' (80 m) |
| Traveling Speed | 44.1 mph (71 km/h) |
| Base Weight (GVW) | 120,747 lbs. (54,770 kg) |
| Transmission Type | Automatic |
| Engine | Volvo Penta TAD720VE |
| Category | All Terrain Cranes |
| Show More | |
| Hide |
DESCRIPTION
XCMG factory's famous 160-ton-used all-terrain crane QAY160.
1. Excellent overall performance
* Lifting performance: The boom is strengthened, with a special 11m jib for wind turbine working condition available, able to lift 65t weight at 72m height and meet the requirements of lifting a 1.5MW wind turbine.
2. Efficient, reliable, and upgraded systems
* The hand acceleration and remote control device are newly added to the operation of the superstructure, so as to reduce operator fatigue and enhance operation safety. Remote control distance can reach 150m, exceeding other competitors.
|
Crane Specifications |
Item |
Unit |
Parameter |
|
|
Dimension |
Overall length |
mm |
15900 |
|
|
Overall width |
mm |
3000 |
||
|
Overall height |
mm |
4000 |
||
|
Wheel base |
Axle 1, Axle 2 |
mm |
2750 |
|
|
Axle 2,Axle 3,Axle 4,Axle 5, Axle 6 |
mm |
1650 |
||
|
Axle 3, axle 4 |
mm |
2000 |
||
|
Track |
mm |
2590 |
||
|
Total mass in travel state |
kg |
70900 |
||
|
Axle load |
Axle 1, Axle 2 |
kg |
11635 |
|
|
Mass |
Axle 3, Axle 4 |
kg |
11815 |
|
|
Axle 5, Axle 6 |
kg |
12000 |
||
|
Power |
Crane superstructure |
Rated power |
kW/(r/min) |
162/2100 |
|
Rated torque |
N.m/(r/min) |
854/1400 |
||
|
engine |
Rated speed |
r/min |
2100 |
|
|
Crane carrier engine |
Rated power |
kW/(r/min) |
380/1800 |
|
|
Rated torque |
N.m/(r/min) |
2400/1200 |
||
|
Rated speed |
r/min |
2000 |
||
|
Travel performance |
Travel speed |
Max. travel speed |
km/h |
71 |
|
Min. stable travel speed |
km/h |
2.1 |
||
|
Min. turning diameter |
m |
24 |
||
|
Min. ground clearance |
mm |
278 |
||
|
Approach angle |
° |
25 |
||
|
Departure angle |
° |
20 |
||
|
Braking distance (at 30km/h with full load) |
m |
≤ 10 |
||
|
Max. grade-ability |
% |
48 |
||
|
Fuel consumption for 100km |
l |
80 |
||
1.What’s the warranty policy for XCMG reconditioned machines?
The warranty policy does not cover the covering parts and wearing parts. For engine, gearbox, hydraulic pump, distriutor valve and electric system, the warranty period will be 3 months or 500 working hours whichever comes first. If there is any problem within warranty period, XCMG will provide solutions accordingly.
2.How about the quality of your machine?
The procedure of recondition is taking the same criterion of brand new XCMG machines, therefore, quality of machines will be guaranteed. They are ready to work for you and XCMG will provide test report from professtional institute.
3.Are you the original manufacturer?
Yes! XCMG is leading construction machinery industry in China and XCMG can provide a complete range of constrcution machineries.
4.Can you satisfy my special requirement?
As the manufacturer,XCMG will review the special requirement and recondition it as per request (if possible).
5. What is acceptable payment terms?
Usually XCMG will accept T/T before shipment or 100% Letter of Credit at sight.
If any other questions, please feel free to contact with us.
$188,000 USD
