Terex HC 285 285-ton Lattice Boom Crawler Crane For Sale or RentLocation: Burleson, TX, USA Get a Shipping Quote
|Status||For Sale or Rent|
|Stock Unit #||7150|
|Main Boom Length||300' (91.5 m)|
|Jib Extension Length||80' (24.4 m)|
|Maximum Counterweight||263,000 lbs. (119,295 kg)|
|Base Weight (GVW)||100,400 lbs. (45,540 kg)|
|Sub Category||Lattice Boom|
Please Call for Sale Price & Availablity.
Rental Rates with Operator *** TWO (2) Units available for RENT**
The 285-ton USt (258 metric ton) lifting capacity Terex HC 285 (American Crane Corporation) lattice boom crawler crane comes fully equipped with 80' - 300' (24.4 - 91.5 m) of main lattice boom (92HI tubular chord boom and offset boom tip) and a 100' of lattice jib extensions (16HL fixed jib) for a total maximum system length of 378' (115 m) and a 280' (85.3 m) maximum hook radius.
The 10.5' crane width and 12' height full crane system transport with 300' boom, 100' jib, plus full counterweight of 263,000 lbs. (120 mt) comprises approximately sixteen loads.
This model crane features power up/down, free gall on main and auxiliary drums optional, shockless stop system gradually retards operating speed when crane approaches lifting load or boom limits, two-speed travel, and hydraulically removable counterweight system.
Standard power is a Cummins QSL9 350 HP (261 kW) diesel engine.
