XCMG QUY75 Specifications
The XCMG QUY75 Lattice Boom Crawler crane is the first Chinese manufacturer to use pilot proportional control technology in crawler cranes, and currently offers a full range... Show More
XCMG QUY75
(Cranes, Hoists & Material Handlers : Crawler Cranes)
The XCMG QUY75 Lattice Boom Crawler crane is the first Chinese manufacturer to use pilot proportional control technology in crawler cranes, and currently offers a full range of products from 35ton to 4000ton.
| XCMG QUY75 | |||
| Crane Specifications | Unit | Parameter | |
| Max. rated lifting capacity | Basic boom | t | 75 |
| Fixed jib | t | 6.5 | |
| Max. load moment | kN-m | 2744 | |
| Main boom length | m | 13-58 | |
| Main boom Luffing angle | ° | 9-18 | |
| Fixed jib length | m | 30-80 | |
| Winch max. single line speed( no load, at 5th layer) | m/min | 120 | |
| Boom luffing gear max. single line speed( at 1th layer) | m/min | 57 | |
| Max. swing speed | r/min | 2.4 | |
| Max. travel speed | km/h | 1.2 | |
| Max. grade-ability | % | 30 | |
| Mean ground pressure | MPa | 0.087 | |
| Engine output power | kW | 200 | |
| Gross vehicle mass (including main hook block and 13m boom) | t | 61 | |
| Max. weight of the single unit in travel configuration | t | 39 | |
| Max. dimension of single unit in travel configuration (L×W×H) | m | 12.6×3.32×3.23 | |
