Tadano GR-800XL-4 Specifications
The 80-ton USt (72.6 meteric ton) lifting capacity Tadano GR-800XL-4 Rough Terrain Crane has a maximum lifting height of 211.3 feet and features an upgraded redesign from... Show More
Tadano GR-800XL-4
(Cranes, Hoists & Material Handlers : Rough Terrain Cranes)
The 80-ton USt (72.6 meteric ton) lifting capacity Tadano GR-800XL-4 Rough Terrain Crane has a maximum lifting height of 211.3 feet and features an upgraded redesign from the traditional Tadano RT style cranes usually. The extra boom length of 154 ft/46.9m is usually reserved for the 100 US ton (90.7t) class crane and with a transportation weright under 100, 000 pounds (45 metric ton) this crane is extremely easy to transport to and from lifting jobsites.
Crane Specifications
| Max Lifting Capacity | 80 tons |
| Max Lift Height | 211.3′ |
| Boom Length | 39.4' - 154.2′′ |
| Maximum Working Radius | 160′ |
| Number of Axles | 2 |
| Jib Length | 11.8' or 18′′ |
| Counterweight | 9, 600 lbs |
| Drive | 4x4x4 |
| Gross Vehicle Weight | 99, 800 lbs |
| Length | 565.9″ |
| Width | 130.5″ |
| Height | 150.4″ |
Features Include
| Smart Chart |
| Titable cab |
| Asymmetrical Outrigger set-up |
| Slow-Stop |
| Eco Mode System |
| Fuel Consumption Monitor |
| Automatic Pump Disconnect |
| Self-Removable Counterweight |
| Sequential and non-Sequential telescoping modes |
| HELLO-NET |
| HELLO-DATA LINK |
