Designed for the International Crane Market, the 55-ton (metric) Sany SRC550C is a rough-terrain crane purpose-built for versatile lifting operations in challenging environments, including construction sites, oil fields, and off-road industrial projects.

Crane Specifications

Feature Specification
Max. Lifting Capacity     55 metric tons (3m radius)
Main Boom Length 11.5 m – 43 m (5 Sections)
Max. Lifting Height 43 m (Boom) / 59 m (with Jib)
Jib Length 16 m (Lattice type)
Engine DongFeng Cummins ISDe 270 30 (198 kW / 269 HP)
Drive / Steer 4 x 4 x 4 (4-wheel drive, 4 steering modes)
Max. Travel Speed 25–40 km/h
Operating Weight Approx. 44, 900 kg

Core Features

  • High Maneuverability: Designed for "rough terrain, " it features high ground clearance (approx. 503 mm) and four-wheel steering modes (front-wheel, rear-wheel, four-wheel, and crab-steer). This allows it to navigate tight, muddy, or uneven job sites where a standard truck crane would get stuck.

  • U-Shaped Boom: The 5-section telescopic boom features a high-strength steel U-shaped cross-section. This design provides a better strength-to-weight ratio and increased side-load resistance compared to older rectangular designs

  • Precision Control: It uses a load-sensing hydraulic system and a constant power control pump. This allows for "micro-mobility, " meaning the operator can move heavy loads very slowly and precisely.

  • Safety Technology: The crane is equipped with the SYMC Load Moment Limiter (LML), which provides real-time data on boom angle, length, and weight. It includes automatic "dead-man" cut-offs if the crane approaches its tipping point or structural limit.

  • Operator Comfort: The cab is a one-man ergonomic design with 360° visibility, air conditioning, and a color monitor that displays all safety and engine parameters in multiple languages.

Crane Applications

Because it is self-propelled and can travel with a load (pick-and-carry), the SRC550C is commonly used for:

  1. Infrastructure Projects: Bridge building and highway construction.

  2. Petrochemical Plants: Maintenance and equipment installation in narrow corridors.

  3. General Construction: Setting steel beams, moving concrete forms, and loading/unloading materials on unpaved ground.
