Sany SCC8100-2 Specifications
Sany SCC8100-2
(Cranes, Hoists & Material Handlers : Crawler Cranes)
The Sany SCC8100-2 lattice boom crawler crane features a Cummins QSL9, 341 hp @ 1800 rpm engine. The Hydraulic system has Rexroth pumps and drive motors. Includes Sany-designed LMI with large display screen and extendable tracks,
Two configurations are available:
Main Boom and Fixed Jib or main boom available in Tubular and Angle construction
Standard features:
– Main drum bail limits
– Main drum and rear counterweight camera system
– Basic machine lighting package
– Aircraft warning light
Maximum Capacity @ Radius 110 US T @ 12.5 ft
Main Boom 3, 6 & 9 Meter Sections 42.7 ft – 229.7 ft
Fixed Jib Length 29.5 ft – 73.8 ft.
Main Winch - Rated Line Pull 20, 944 lb
Wire Rope Diameter 24 mm
Weight Basic Machine (With Track Frames & Boom Butt) 99, 208 lb
Total Counterweight (Series 2) 82, 450 lb
Length Basic Machine - Transport (With Track Frames & Boom Butt) 43.4 ft
Height Basic Machine - Transport (With Track Frames & Boom Butt) 11.5 ft
Width Basic Machine - Transport (With Track Frames & Boom Butt) 11.5 ft
Tail Swing 16 ft 5 in
