The Kobelco SL6000G is the European variant of the SL6000 series, a powerful heavy-duty lattice boom lifting crane with a max capacity of around 600 tons (550 metric tons), designed for large infrastructure and energy projects. The SL6000 series features advanced self-assembly, excellent transportability, and multiple configurations (Standard, Heavy Lift, Super Heavy Lift) for various boom and jib setups, offering high performance with features like a dust-resistant swing bearing and an environmentally conscious engine.

Lift Enhancer

HL Mast

STD

-

HL

30 m

SHL

30 m

Additional Weight

STD

-

HL

-

SHL

~ 250 t

Heavy Duty Crane Boom

Max. Lifting Capacity

STD

450 t
6.7m

HL

370 t
8.3m

SHL

550 t
8.3m

Length

STD

24 ~ 84 m

HL

36 ~ 84 m

SHL

36 ~ 84 m

Luffing Boom

Max. Lifting Capacity

STD

300 t
10 m

HL

300 t
9.3 m

SHL

300 t
20.0 m

Length

STD

30 ~ 84 m

HL

36 ~ 84 m

SHL

36 ~ 84 m

Long Boom

Max. Lifting Capacity

STD

98 t
18.0 m

HL

98 t
20.0 m

SHL

98 t
30.0 m

Length

STD

90 ~ 108 m

HL

90 ~ 108 m

SHL

90 ~ 126 m

Heavy Fixed Jib

Type

STD

A

HL

B

SHL

B2

C

Max. Lifting Capacity

STD

105 t

HL

120 t

SHL

120 t

105 t

Max. Combination(Boom)

STD

78 m

HL

78 m

SHL

78 m

102 m

Max. Combination(Jib)

STD

18 m

HL

18 m

SHL

18 m

18 m

Luffing Jib

Max. Lifting Capacity

STD

195.1 t

HL

200 t

SHL

200 t

Max. Combination(Boom)

STD

60 m

HL

66 m

SHL

84 m

Max. Combination(Jib)

STD

72 m

HL

72 m

SHL

84 m

Luffing Angle

66° ~ 86°

Power Plant

Model

HINO E13C-VV

Rated Engine Output
(Max. Engine Output)

320 kW / 2, 000 min-1{rpm}
(330 kW / 1, 800 min-1{rpm})

Fuel Tank Capacity

600 L

Hoist Winch (H1, H2)

Max. Line Speed

110 m/min (1st layer)

Rated Line Pull (Single line)

137 kN {14.0 tf}

Wire Rope Diameter

28 mm

Wire Rope Length

830 m

Working Speed

Swing

0.9 min-1 {rpm}

Travel

1.0 / 0.6 km/h

Hydraulic System

Pumps

7 variable displacement

Max. Pressure

32 MPa {326 kgf/cm2}

Oil Quantity (at the reference level)

710 L

Weight

Operating Weight*

Approx. 444 t

Ground Pressure*

142 kPa {1.5 kgf/cm2}

Counterweight

200 t (Upper)
