Jekko SPX532CL Specifications

Produced in Italy, the Jekko SPX532CL is a specialized full-electric model variant designed for indoor use and zero-emission-sensitive environments, powered by a lithium battery pack (48V-3F) that offers zero emissions, lower noise levels, and maintenance-free operation for over one full workday. It includes an on-board fast charger that can reach 80% capacity in approximately 3 hours

The Jekko SPX532CL offers the same specifications and dimensions as the standard Jekko SPX532 crawler tracked high-performance compact mini crane, designed for lifting and maneuvering in tight spaces, but is slightly heavier due to the battery packs.

Jekko mini cranes are sought after by the glass facade industry, crane rental firms, industrial maintenance, and the building sectors. This next-generation, user-friendly mini crane ensures top-level performance with one of the most advanced outrigger stability systems on the crane market.

• Compact Size: Fits through a standard single door (less than 80 cm wide).
• High Lifting Capacity: Maximum lifting capacity of 3.2 tons.
• Advanced Stability System: Ensures safe operation with variable stabilization at different outrigger angles, thanks to a sophisticated sensor system and geometric stability control.
• User-Friendly Operation: Intuitive radio remote control and digital hydraulic pump for smooth and precise movements, with available options like a touchscreen display.
• Versatile Lifting Modes: Can lift using both the hook block and hoist method.
• Expandable Tracks: Enhance stability and adapt to different terrains.
• Optional Attachments: Can be equipped with various attachments, such as hydraulic jibs, glass manipulators, grabber beam manipulators, and lifting beams, making it adaptable to diverse applications.

Specifications

• Dimensions: 3255 x 770 x 1960 mm (Length x Width x Height).
• Max Reach: 56' 9" (17.3 meters) with jib.
• Max Working Height: ( 6' 9"(17.3 meters) with jib.
• Max Radius: 48' 7" (14.8 meters)
• Weight: Approximately 6, 105 lbs (2, 520 kg)
