Jekko SPX532CL2 Specifications

The Jekko SPX532CL-2,  also known as the Jekko SPX532CL2,  is a compact,  100% electric mini crane with a lifting capacity of up to 3, 200 kg. With a width of only 77 cm, a wide range of accessories, and many installation options, this Jekko mini crane can handle everything from precision lifting indoors to demanding tasks outdoors.

The Jekko SPX532CL-2 combines compact design, high performance and environmentally friendly technology. With 100% electric lithium operation, this mini crane operates quietly and emission-free, making it ideal for both sensitive environments and places with limited space. The transport width of only 77 cm allows access to areas where traditional cranes cannot reach. The crane has a lifting capacity of up to 3, 200 kg, a reach of 14.8 meters and a lifting height of 17.3 meters with jib. Operation is via a wireless remote control, ensuring precision and control for all types of lifting.

Accessories for Jekko SPX532CL-2

The SPX532CL-2 can be set up with a single-line with one cut and 125 meters of wire, giving a capacity of up to 800 kg – perfect for lifting from building roofs, for example. For heavier tasks, the crane can be configured with a block with four cuts, increasing the capacity to 3, 200 kg with 12 meters of wire.

The accessories make the crane extremely versatile. The fly jib with crane hook and wheels provides extra reach, while the searcher hook allows for lifting at different angles. For special tasks, we offer the JEK-JIB500GR, a powerful gripper for pipes and steel profiles, as well as the JEK-JVM800R – a fixed vacuum suction that can be configured with, for example, 4, 6 or 8 suction cups and lift 400, 600 or 800 kg respectively. This makes the crane ideal for installing glass, metal sheets and paroc sheets.

The Italian made Jekko SPX 532 is a crawler tracked high-performance compact mini crane designed for lifting and maneuvering in tight spaces which is sought after by the glass facade industry, crane rental firms,  industrial maintenance, and the building sectors. This next-generation user-friendly mini crane ensures top level performance with one of the most advanced outrigger stability systems on the crane market.

• Compact Size: Fits through a standard single door (less than 80 cm wide).
• High Lifting Capacity: Maximum lifting capacity of 3.2 tons.
• Advanced Stability System: Ensures safe operation with variable stabilization at different outrigger angles, thanks to a sophisticated sensor system and geometric stability control.
• User-Friendly Operation: Intuitive radio remote control and digital hydraulic pump for smooth and precise movements, with available options like a touchscreen display.
• Flexible Power Options: Available with lithium battery technology or a combination of diesel and electric (single phase or three phase) power sources.
• Versatile Lifting Modes: Can lift using both the hookblock and hoist method.
• Expandable Tracks: Enhances stability and adapts to different terrains.
• Optional Attachments: Can be equipped with various attachments like hydraulic jibs, glass manipulators, grabber beam manipulators, and lifting beams, making it adaptable to diverse applications.

Specifications

• Dimensions: 3255 x 770 x 1960 mm (Length x Width x Height).
• Max Reach: 17.3 meters (56' 9") with jib.
• Max Working Height: 17.3 meters (56' 9") with jib.
• Max Radius: 14.8 meters (48' 7").
• Weight: Approximately 2, 350 kg (6, 105 lbs).

Brand

Jekko

Model

SPX532CL-2

Max Lifting Height

12.1m

Max Lifting Capacity

3.2t x 1m

Weight

2, 520kg

Speed

0~1.8 km/h

Working Radius

9.5m

• Slewing Angle: 360°
• Gradeability: 20°
• Power Source: Lithium battery type
• Electric Engine Voltage (V): 48
• Electric Engine Power (kW): 7
• Stowed Dimension (W x L x H) (m): 0.77 x 3.145 x 1.965
