Gehl CT7-23 Specifications

Gehl designs, manufactures and distributes compact equipment for the Agricultural and Construction markets including Skid Loaders, Articulated Loaders, Track Loaders, Telescopic Handlers, Compact Excavators, and Asphalt Pavers.

RS Series Telescopic Handlers are Reaching New Heights

Telehandler Jobsites demand superior performance, and that's what the RS Series Telescopic Handlers provide. Lifting up to 12, 000 pounds (RS12-42) with lift heights up to 55 feet (RS10-55), these machines provide the extra working capacity without sacrificing the comfort and features expected in the RS Series Telescopic Handlers.

Rear Axle Stabilization - Stabilizer cylinder locks the rear axle to improve stability whenever the boom is raised 60 degrees or the parking brake is applied.

Outriggers - Add stability and increase capacity when lifting to full height.

Internal Wet Disc Brakes - Provide excellent stopping capability and longer life.

Heavy-Duty Booms - Robust boom design easily handle 5, 000 to 12, 000 pound rated loads.

• RS4-14

  Rated Lift Capacity (kg): 4, 400 lbs. (1996)
  Gross Power (kW): 56.3 hp (43)
  Maximum Lift Height (m): 9' 0" (2.7)

• RS5-19 GEN:3

  Rated Lift Capacity (kg): 5, 500 lbs. (2495)
  Gross Power (kW): 68 hp (50.7)
  Maximum Lift Height (m): 19' 1" (5.8)

• RS6-34 GEN:3

  Rated Lift Capacity (kg): 6, 000 lbs. (2722)
  Gross Power (kW): 74 hp (55)
  Maximum Lift Height (m): 34' 3" (10.4)

• RS6-42 Mark74

  Rated Lift Capacity (kg): 6, 600 lbs. (2994)
  Gross Power (kW): 74 hp (53)
  Maximum Lift Height (m): 42' 0" (12.8)

• RS6-42 GEN:3

  Rated Lift Capacity (kg): 6, 600 lbs. (2994)
  Gross Power (kW): 120 hp (89)
  Maximum Lift Height (m): 42' 0" (12.8)

• RS8-42 Mark74

  Rated Lift Capacity (kg): 8, 000 lbs. (3629)
  Gross Power (kW): 74 hp (53)
  Maximum Lift Height (m): 42' 0" (12.8)

• RS8-42 GEN:3

  Rated Lift Capacity (kg): 8, 000 lbs. (3629)
  Gross Power (kW): 120 hp (89)
  Maximum Lift Height (m): 42' 0" (12.8)

• RS8-44 Mark74

  Rated Lift Capacity (kg): 8, 000 lbs. (3629)
  Gross Power (kW): 74 hp (53)
  Maximum Lift Height (m): 44' 0" (13.4)

• RS8-44 GEN:3

  Rated Lift Capacity (kg): 8, 000 lbs. (3629)
  Gross Power (kW): 120 hp (89)
  Maximum Lift Height (m): 44' 0" (13.4)

• RS9-50 GEN:3

  Rated Lift Capacity (kg): 9, 000 lbs. (4082)
  Gross Power (kW): 120 hp (89)
  Maximum Lift Height (m): 50' 1" (15.3)

• RS10-44 GEN:3

  Rated Lift Capacity (kg): 10, 000 lbs. (4536)
  Gross Power (kW): 120 hp (89)
  Maximum Lift Height (m): 44' 0" (13.4)

• RS10-55 Mark74

  Rated Lift Capacity (kg): 10, 000 lbs. (4536)
  Gross Power (kW): 74 hp (53)
  Maximum Lift Height (m): 55' 1" (16.8)

• RS10-55 GEN:3

  Rated Lift Capacity (kg): 10, 000 lbs. (4536)
  Gross Power (kW): 120 hp (89)
  Maximum Lift Height (m): 55' 1" (16.8)

• RS12-42 GEN:3

  Rated Lift Capacity (kg): 12, 000 lbs. (5444)
  Gross Power (kW): 120 hp (89)
  Maximum Lift Height (m): 42'

DL Series Telescopic Handlers is a Tower Over The Rest

Get everything you ever wanted in a telescopic handler with the DL Series from Gehl. High Lift. Long Reach. Big Load Capacity. These machines do it all. With unmatched versatility, visibility and comfort, the DL Series provides performance you can count on. A full line of easy-to-install attachments allow you to lift in the morning and load in the afternoon.

Towering Lift Heights - Lift heights from 40-feet (13.5 m) to 55-feet (16.8 m).

High Performance- Robust, heavy-duty booms with lift capacities of 7, 000 lbs. (3175 kg) to 12, 000 lbs. (5443 kg).

Turbo Power - Standard 115 hp (86 kW) turbocharged Interim Tier IV engine.

• DL11-44 GEN:3

  Rated Lift Capacity (kg): 11, 000 lbs. (4990)
  Gross Power (kW): 120 hp (89)
  Maximum Lift Height (m): 44' 4" (13.5)

• DL11-55 GEN:3

  Rated Lift Capacity (kg): 11, 000 lbs. (4990)
  Gross Power (kW): 120 hp (89)
  Maximum Lift Height (m): 55' 1" (16.8)

• DL12-40 GEN:3

  Rated Lift Capacity (kg): 12, 000 lbs. (5444)
  Gross Power (kW): 120 hp (89)
  Maximum Lift Height (m): 40' 4" (12.3)

• DL12-55 GEN:3

  Rated Lift Capacity (kg): 12, 000 lbs. (5443)
  Gross Power (kW): 120 hp (89)
  Maximum Lift Height (m): 55'
