The 130-ton (120 mt) lifting capacity Tadano GTC-1200 Telescopic-Boom Crawler Crane is designed for bridge building, civil construction, foundation work, and general lifting applications.

Equipped with a standard 42' 1" to 155' 0" full-power round telescopic boom with two extension modes.

• HELLO-NET telematics
• Tadano AML-C load-moment system

With the crawler tracks extended, the GTC-1200 can "Pick and carry" and swing 360 degrees with a full-capacity load and also lift lighter loads with retracted crane crawler tracks enabling the crane operator to telescope and raise the boom with a full-capacity load on the hook, so the crawler tracks can counter-rotate for pivot turns.

The maximum boom-and-jib combination gives a maximum tip height of 268 ft. At that height, the GTC-1200 lifts 5, 300 lbs. at the 30-ft. minimum radius boom-and-jib combination, and an impressive 1, 700 lbs. at a 161-ft. radius with 210 ft. of tip height.

The crane swing continuously through 360° at up to 2 rpm on a shear-ball bearing. The swing function is driven hydraulically, and the operator can select either free or closed-loop swing.

The hydraulically powered crawlers are 23' 9" long, and feature 36-inch wide treads. The crawlers can be extended laterally to 19' 1" for lifting stability or retracted to 11' 9" for maneuvering and lifting in tight spaces.

CRANE SPECIFICATIONS

• CRANE CAPACITY:  130 tons at 10 feet

• BOOM:  5-section, 42’1” – 155’0”

DIMENSION

• Overall Length  51’9”
• Overall Width (tracks extended) 19’0”
• Overall Width (tracks retracted) 12’0”
• Overall Width (tracks removed) 9’9”
• Overall Height 14’10”

CRANE (GVW) MASS

• Gross Vehicle Mass (Standard Equipment Package): 262, 600 lb
• Maximum Counterweight:  Upper: 70, 000 lb / Carbody: 20, 000 lb

PERFORMANCE

• Travel Speed 0.5 mph – 1.6 mph
• Gradeability 52%
• Winch Line Pull (first Layer) 23, 560 lb
• Winch Line Speed (4th layer) 317.3 ft/min

ENGINE

• Cummins QSB6.7 350hp @ 2, 100RPM

Key Features

• 130-tons pick-and-carry capacity through 360°.
• Two-piece bi-fold (33.5′ / 59.1’) lattice boom extension & offsettable jib for up to 229ft tip height
• Heavy Lift Jib – 12.5 ft, 88, 000 lb maximum capacity
• Optional – 2 piece lattice jib inserts for 105′ total jib for up to 269 ft lifting height
• Tadano AML-C LMI system
• Work area limitations with soft stop
• Winches with grooved drums, cable followers and 3rd wrap shutdown
• Self Erecting Crane
• Carbody Jacks with radio remote control and self leveling feature
• Unladen ground bearing pressure of 15.2 psi
• Hydraulic on-the-fly track frame retraction and extension
• Automatic lubrication system for slewing ring and boom pin
• 360 degree house lock
• Hello-Net Telematics
• 3 remote control work lights
• 3 video cameras for the winch view, rear view, and blind side view

Optional Equipment

• Crane-mounted hydraulic tool circuit with 50′ retractable hose reel
• WP-750 work platform mounts to the boom tip or a 33.5′ lattice boom extension
• Cold-weather heater options
• Controlled free-fall winches
• Radio remote control
• Cab Mounted FOPS
• Steel flat shoe
