Demag AC 535 Specifications

The Demag AC 535 is a high-performing 200-ton rated USt lifting capacity (180-ton metric ton all-terrain crane. This crane

• Lifting capacity: 200 Ust (180 mt).
• Main boom: Equipped with a five-section telescopic main boom that extends from 14.7 meters (48.2 feet) up to 60.0 meters (197 feet).
• Jib: Features an optional fixed jib system with extensions ranging up to 32.5 meters (107 feet). It can also be configured with a luffing jib for a greater working range.
• Maximum tip height: Can reach up to 95 meters (311 feet) with extensions.
• Counterweight: The maximum counterweight is 64 metric tons (141, 000 lbs).
• Engine: Mercedes-Benz engines, while some reconditioned or updated versions may have different engines, such as a Cummins.

Tadano supports this crane, as they acquired the Demag AT product line from Terex.
