Link-Belt TCC-800 Specifications
The Link-Belt TCC-800 is an 80-ton (75 mt) lifting capacity Telescopic Boom Crawler Crane that self-assembles with 38, 500 lbs (17, 463 kg) of upper counterweight and two... Show More
Link-Belt TCC-800
(Cranes, Hoists & Material Handlers : Crawler Cranes)
The Link-Belt TCC-800 is an 80-ton (75 mt) lifting capacity Telescopic Boom Crawler Crane that self-assembles with 38, 500 lbs (17, 463 kg) of upper counterweight and two 3, 000 lb. (1, 360 kg) sections of carbody counterweight.
| Base Rating | 80 Ton @ 9' (75 mt @ 3 m) | ||
| Main Boom | Four Section Formed Boom | ||
| Length (min-max) | 38.6'-120.1' (11.8 m-36.6 m) | ||
| Telescope System | Full Power | ||
| Max Tip Height | 184.5' (56.24m) | ||
| Engine | Cummins QSB 6.7L | ||
| Horsepower | 232 hp (173kW) @ 2, 000 rpm | ||
| Nominal Capacity @ Radius | 80 Ton @ 9' (75mt @ 3m) | ||
| Maximum Line Pull | 18, 392 lbs (8, 342 kg) | ||
| Max Line Speed No Load | 449 fpm (137mpm) | ||
| Standard Upper Weights | 38, 500 lbs (17, 463 kg) | ||
| Standard Lower Weights |
|
||
| Main Transport Load | 99, 621 lbs (45, 187 kg) | ||
| Overflow Loads | 1 | ||
The Link-Belt TCC-800 transports on specialized carriers in two loads; the main lower crane carrier transports at under 100, 000 lbs (45, 359 kg) with fly, side frames attached, hook block and ball, lifting sheave and full tank of fuel.
