Grove TMS800-2 Cranes for Sale and Rent
The 80-ton Ust Grove TMS800-2 is a truck-mounted crane that is the successor to the highly popular Grove TMS800E that utilizes features developed for larger cranes and scales... Show More
Sort By:
SOLD 2025 Grove TMS800-2 Telescopic Boom Truck Crane For Sale
| Location |
Cleveland, Ohio US 2031 miles |
|---|---|
| Make | Grove |
| Model | TMS800-2 |
| Tons | 80.00 |
| Year | 2025 |
SOLD 2025 Grove TMS800-2 Telescopic Boom Truck Crane.
80 Truck Crane
S/N: 237908
Single X12 Cummins Turbo Charged, After Cooled Diesel
On Highway EPA, CARB Compliant
128' 5 Section TWIN-LOCK MEGAFORM Boom w/ Auxiliary Point
2 Drum Machine - 17,160 Lb. Line Pull
20 degree Tilt Cab
Proven CCS Operating System
Load Sense Hydraulic System
4 Position Outrigger System ( 0%, 54%, 77% and 100%) w/ Monitoring System
Air Ride Suspension Front and Rear
More Crane Options:
33' - 56' Manual Bi-Fold Offset Swing-a-Way Jib
Auxiliary Lighting and Convenience Package
Trailering ...
The 80-ton Ust Grove TMS800-2 is a truck-mounted crane that is the successor to the highly popular Grove TMS800E that utilizes features developed for larger cranes and scales them down into a highly efficient "taxi crane" configuration.
Crane Specifications
- Maximum Capacity: 80 USt
- Boom Length: 40 ft to 128 ft (12.2 m to 39.0 m) four-section, MEGAFORM, Twin-Lock boom
- Maximum Tip Height: 137.0 ft (41.8 m)
- Engine: Cummins X12 6-cylinder turbocharged diesel (475 bhp / 1, 700 lb-ft torque)
- Transmission: Eaton manual or automated (Eaton Fuller UltraShift PLUS optional)
The completely redesigned, lightweight carrier permits excellent roadability. The crane can carry its entire 28, 000 lbs of counterweight without exceeding axle and tire limits where road regulations allow. For regions with strict gross vehicle weight (GVW) legalities, it can carry 18, 000 lbs of counterweight and stay comfortably under 100, 000 lbs GVW and 25, 000 lbs per axle. By eliminating wing weights, it maintains a narrow travel width of just 8.3 ft.
The crane features raised rear outrigger boxes (by ~5 inches) and front outrigger jacks (by 3.5 inches) to drastically improve ground clearance and departure angles. It is also the first TMS crane to offer MAXbase as an option. This technology allows the outriggers to extend asymmetrically, accelerating setup on congested or irregular job sites while increasing overall lifting capacities.
The TMS800-2 as the larger 115-ton aluminum premium carrier shares the same lower Grove TMS9000-2. The superstructure cab features the Manitowoc Group proprietary Crane Control System (CCS) with intuitive jog-dial displays and integrated cameras to safely monitor blind spots and hoists.
