Tadano GR-1200XL Specifications

The Tadano GR-1200XL is its largest 2-axle Rough Terrain crane. This rough terrain has a maximum lifting capacity of 120 US tons, and a boom measuring 183.7 ft.

Product Concept

The GR-1200XL is developed for industrial energy sites, especially in North America. Cranes used for the construction and maintenance of these sites are required to have high maneuverability, durability, and lifting performance under tight conditions. In addition, there is a need for cranes in the 100-ton class to have higher reaching, longer boom lengths and larger lifting capacities.

Performance

The GR-1200XL has the largest maximum lifting capacity in Tadano’s 2-axle Rough Terrain Crane product line. It has a strong and light high tensile steel rounded boom that features a single telescopic cylinder. The crane has a 184.0 ft lifting height and a 144.3 ft load radius.

Extra reach is provided by a jib which extends the lifting height to 241.4 ft. with a load radius reaching 153.8 ft.

Compact Carrier and Maneuverability

The GR-1200XL has a compact carrier, which in size is almost the same as Tadano’s GR-1000XL. This compactness provides high maneuverability and easy transportability.

New Smart Chart System

With conventional cranes, outriggers extended to their maximum length provide a uniform, circular rated load capacity footprint over 360° of slewing angle. However, thanks to Tadano’s newly developed Smart Chart, a safety device and control system, the crane can achieve a square-shaped rated load capacity footprint, with extended “corners” over the outriggers that increase the load radius, depending on the degree to which the outriggers are extended.

Environmentally Friendly Crane

The GR-1200XL comes equipped with Tadano’s state-of-the-art fuel monitoring system, Eco-Mode, which reduces fuel consumption when the crane is being operated, and Positive Control, which reduces fuel consumption when the crane is on standby.

Hello-Net

Using Hello-Net telematics, customers can monitor their crane activity, work history, machine position data, and maintenance information with computers and mobile devices. Through this system, Tadano offers advanced customer support.

Dimensions – GR-1200XL

Overall Length – Approx. 47’4-7/8”

Overall Carrier – Length Approx. 28’4-3/4”

Overall Width – Approx. 10’10-1/2”

Overall Height – Approx. 12’5-3/8”
