Manitex TC40127 Cranes for Sale and Rent
Manitex TC40127 Specifications
The Manitex TC40127 is a model in the Manitex TC400 product line of high-capacity, commercial-chassis mounted telescopic boom truck cranes with a maximun lifting capacity... Show More
Sort By:
2018 Manitex TC40127 40-Ton Boom Truck Crane For Sale
| Location |
Raleigh, North Carolina US 2227 miles |
|---|---|
| Make | Manitex |
| Model | TC40127 |
| Tons | 40.00 |
| Year | 2018 |
Manitex TC40127, 40 US ton Boom Truck
-127' Main Boom
-30.5' - 55' Jib
-Oil Cooler
-Outrigger and rigging remote
Mounted on Peterbilt 567 with MX-13, 510 HP engine, Allison automatic transmission, locking rear axles and wheel ends, aluminum wheels, AM/FM Radio, Bluetooth capable, 29,900 miles
2019 Manitex TC40127 40-Ton Boom Truck Crane For Sale
| Location |
Raleigh, North Carolina US 2227 miles |
|---|---|
| Make | Manitex |
| Model | TC40127 |
| Tons | 40.00 |
| Year | 2018 |
SOLD
Manitex TC40127, 40 USt, 127' Main Boom, 30.5' – 55' Jib, Oil Cooler. Mtd on a Peterbilt 567 Chassis, MX-13 / 510 HP, Auto Trans, Locking Rear Axles, and Wheel Ends, Alum Wheels, AM/FM Radio, Bluetooth Capable, and much more.
Manitex TC40127 45-Ton Un-Mounted Boom Truck Crane For Sale
| Location |
St. Augustine, Florida US 2177 miles |
|---|---|
| Make | Manitex |
| Model | TC40127 |
| Tons | 45.00 |
| Year | 2020 |
SOLD
MANITEX TC40127—BOOM TRUCK
FEATURES
• 45 Ton (40,8 mt) Capacity
• 5-Section 142’ (43,3 m)
• 2-Section 31’ (9,4 m) to 55’ (16,8 m) Telescopic Jib
• 204’ (62,1 m) Maximum tip Height with Telescope Jib 152’ (46,3 m) Maximum Main Boom Tip Height
• Self-Lubricating Boom Slider Pads
• Wired Anti-Two Block System – Audible warning and shutoff functions prevent hook form contacting boom point. Switch is potted to ensure reliability.
• Without Speed Planetary Grooved Drum Hoist With Negative Draft Flange and Rope Tensioner
• Auxiliary Hoist Option
• Hoist Drum Rotation Indicator
• Third Wrap Limiter...
Manitex TC40127
(Cranes, Hoists & Material Handlers : Boom Trucks)
The Manitex TC40127 is a model in the Manitex TC400 product line of high-capacity, commercial-chassis mounted telescopic boom truck cranes with a maximun lifting capacity of 40 USt (36.3 metric ton) that is designed for multi-industry crane lifting applications like residential construction, steel erection, and bridge infrastructure projects.
Crane Specifications
| Max. Crane Capacity | 40 USt | |||
|---|---|---|---|---|
| Main Boom Length | 127 ft | |||
| Boom Extension | 30.8 ft – 55.1 ft | |||
| Max. Tip Height | 190 ft | |||
| Max. Counterweight | 2, 000 lbs | |||
| Outrigger Bases | 24.3 ft | |||
| Hoist Line Pull | 11, 500 lbs | |||
| Max. Radius | 115 ft | |||
This Manitex TC40127 is now part of the Tadano TC Series and branded as the Tadano TC40127. The Tadano TC line of boom trucks deliver fast setup times, optimized weight distribution, and enhanced stability through an integrated truck-mounted design. Out-and-down outriggers with multiple spread options and a required front bumper stabilizer provide a solid lifting base, while continuous 360° rotation, free-swing capability, and planetary hoist systems offering up to 300 fpm line speed ensure precise, controlled load handling.
Operator comfort and control are supported by a deluxe enclosed, tilting cab equipped with climate control, a heated multi-adjustable seat, and a color display for load moment and engine monitoring. PLC-based crane controls with CANBUS communication, twin dual-axis joysticks, and integrated safety systems—including LMI and work area definition—deliver reliable performance, safe operation, and consistent productivity across demanding lifting applications.
