NEW 2017 ELLIOTT M43R For Sale

NEW ELLIOTT M43R

Standard features:
One new Elliott HiReach M43R having a 48’working height. Basic unit includes base assembly supporting rear mounted rotating turret, hydraulically powered continuous rotation mechanism, oil reservoir mounted to turret box, oil, and manual hydraulic controls mounted to turret. Electronic proportional three stick remote controls on platform. Underslung “A” outriggers at rear and overframe vertical outriggers at front. Steel two section hydraulically telescoping boom with double acting lift cylinder. External cable carrier to boom tip. Hydraulically self-leveling and rotating 30’x54” EZR work platform with remote leveling from platform, and aluminum floor. Power take off, pressure gauge, pump and holding valves on all cylinders. Remote start/stop at upper and lower controls, 12-volt emergency pump with switch at upper and lower controls, PTO hour meter, backup alarm, fire extinguisher, and two body harness. Safety triangle kit and lanyard. LED Lights to include All Bed Marker Lights, Stop, Tail and Turn. Installed on chassis, tested, checked and ready to operate. Unit certified to ANSI A92.2 for Vehicle-Mounted Elevating and Rotating Aerial Devices. Platform capacity 500 lbs.

Additional Options:
• Standard ICC Rear Bumper with Steps and Grab Handles
• Tie Down Rails on Both Sides of Bed
• 2,000 lb. Planetary Winch with Anti-Two-Block Switch, Horn, Cable & Retainer Lug
• 500 lb. Platform Mounted Jib with Hydraulic Winch. Jib Stows in Platform.
• 110 Volt Line to Platform
• (2) Sign Forks on Platform
• Walkway Access to Platform when Boom Stowed (19,500 GVWR Chassis)
• Hot Shift PTO for Automatic Transmission
• Steel Cable Carrier Cover
• Chassis Rating – 19,500 lb. GVWR Non CDL
• HiReach Unit Painted Red, Subframe Painted Black, Outriggers Painted Red (STD)
• 12’6” Steel Bed with LED Lights and Grip Deck Coating
• 98” x 24” W x 30” H Steel Crossbody Box (Requires 24” Shorter Bed)

MOUNTED ON 2017 DODGE 5500 4x2
Mounted on a 2017 Dodge 5500 4x2 tractor chassis with a Cummins 6.7 L I6 320 HP Turbo diesel engine, 50 state emissions, 6 Speed AS69RC HD Aisin Transmission, 19,500GVWR, 7,250 lb. front axle, 13,500 lb. rear axle, P225/70R19.5F front & rear tires, 4.88 axle ration, anti-spin rear axle, PTO prep, 52 gallon rear fuel tank, Platform running boards, Bright bumper/grille, engine block heater, cruise, air conditioning, AM/FM w/CD with Bluetooth, 40/20/40 vinyl split bench seat, power windows & locks, heated mirrors. Color: White
