Manitowoc 2250 300-Ton Lattice Boom Crawler Crane For Sale
Location: Saint Augustine, FL, USAManitowoc Authorized Dealer
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
DESCRIPTION
2250— LATTICE BOOM CRAWLERS
FEATURES
• 372 kW (500 hp) engine
• 18,100 kg (40,000 lb ) clamshell capacity
• 45.4 mton (50 USt) container handling attachment
•EPIC controls
• Fast, efficient self-assembly and disassembly
• Complete crane, maximum boom, jib and counterweight ships on 15 trucks
EPIC®
Manitowoc’s field-proven Electronically Processed Independent Controls (EPIC) system delivers high productivity and precise load control by instantly matching an operator's commands to the crane function. EPIC’s microprocessor maximizes a Manitowoc crane’s function capability and simplifies servicing by pinpointing any problem in the crane’s engine, power transmission and other operating systems. In addition, EPIC increases versatility by easily tailoring a Manitowoc crane’s operation for specialized applications, with or without attachments. EPIC is a key reason no other crane can match the performance and reliability of Manitowoc.
HYDRAULICS
Our closed-loop system provides a separate hydraulic circuit to power each crane function. The result is truly independent, variable-speed operation of the swing, load hoist, boom hoist and travel functions.
FACT™ CONNECTORS
Manitowoc’s Fast Aligning Connection Technology (FACT) quickly aligns crane components for fast, safe assembly and disassembly.
CRANESTAR
CraneSTAR is an exclusive and innovative crane asset management system that helps improve your profitability and reduce costs by remotely monitoring critical crane data.
CRAWLER DRIVE SHAFTS
The crawler drive shafts prevent contaminants from entering the system. By eliminating the need to disconnect hydraulic systems, crawler removal and assembly is safer and easier.
ATTACHMENTS
The liftcrane is equipped with a 21,3 m (70') No. 44 angle-chord boom consisting of a two-piece 12,2 m (40') butt and a 9,1 m (30') heavy-lift top with nine 762 mm (30") diameter roller bearing sheaves on one shaft. Includes rope guides, boom angle indicator, and a 594 kg (1,310 lb) hook and weight ball. The No. 44 boom utilizes steel suspension straps and Manitowoc’s exclusive FACT™ connection system consisting of two vertical pins, two horizontal connection pins, and alignment pads for each boom connection location. Because the 2250 uses steel-strap rigging, boom inserts from the M-250 cannot be used on the 2250. Luffing jib preparation is standard. Manitowoc is committed to providing the most innovative, advanced and comprehensive range of lifting solutions with products that have long set the standard for excellence worldwide: Grove mobile telescoping cranes, Manitowoc lattice boom crawler cranes, Potain tower cranes, National Crane boom trucks and Shuttlelift industrial cranes. In addition to our outstanding product lines, Manitowoc offers outstanding support services through Manitowoc Crane Care.
Similar models may be shown in addition to the featured model. Equipment may be shown with options. Specifications are subject to change without prior notice.
