Link-Belt 100RT 100-Ton Rough Terrain Crane For Sale
Location: Michigan, USALink-Belt Authorized Dealer
This equipment has SOLD
This equipment has SOLD
DESCRIPTION
LIKE NEW LINK-BELT 100RT 100-ton RT NOW IN STOCK AND READY FOR SALE OR RENT
LOWER STRUCTURE
CHASSIS 4x4x4 drive/steering with rear steer indication, all-welded box frame design with tool storage compartment, complete travel light package with backup alarm, full deck fenders with mud flaps, three (3) lockable storage boxes, lifting and tie-down locations, and front towing shackles.
OUTRIGGERS Four single stage beams with Variable Confined Area Lifting Capacities (V-CALC) provide a multitude of selectable outrigger positions. Electronic over Hydraulic controlled from the operator's cab with integral check valves and quick release 24 (60.96cm) diameter steel pontoons, and four outrigger LED lights.
TRAVEL SYSTEM Two planetary axles with two and four drive modes.
SUSPENSION Rear fully independent greaseless 4-link with automatic axle oscillation lockout.
BRAKES Four-wheel full hydraulic disc brakes.
TIRES Four 29.5x 25-34 ply rating, earthmoving type tires on steel disc wheels.
ENGINE Diesel, and 24 volt start / 24 volt charging. [Note: brand, displacement, horsepower, block heater, and emission compliance listed in base item description.]
TRANSMISSION Powershift - Three speed with high/low range for 6 forward and 6 reverse gears.
PUMPS AND HYDRAULICS Two variable displacement, load sense, piston pumps with anti-stall for the boom hoist, boom extend, front and rear winches.
STANDARD OIL, LUBE, AND ANTI-FREEZE Recommended for ambient temperatures between 10°F (-12°C) and 120°F (49°C) - Standard for Stage V/Tier 4F and Tier 3/Stage IIIA emissions. Standard Hydraulic Oil: Grade 68.
GENERAL LOWER ITEMS Right side mirror, 75 gallon (284L) fuel tank with fuel/water separator, and 10 gallon (38L) DEF tank.
REVOLVING UPPERSTRUCTURE
UPPER FRAME All welded high strength steel frame with precision-machined surfaces for all components.
MAIN AND AUXILIARY WINCHES Two-speed, power up / power down winch package includes independent hydraulic controlled / pilot operated axial piston-type motor with disable switch, planetary gear reduction unit, automatic controlled spring applied / hydraulic released multiple disc brake, viewing camera, and electronic drum rotation indicator. Drum includes grooved laggings and are mounted on anti-friction bearings. Hoist drum cable followers (rollers) and 1st layer indicator and 3rd wrap function kick-out.
WIRE ROPE Main Winch: 850 ft (259m) of .75 in (19mm) 37x7 rotation resistant (TYPE KC) rope. Auxiliary Winch: 600 ft (182.8m) of .75 in (19mm) 37x7 rotation resistant (TYPE KC) rope.
SWING Includes independent hydraulic controlled / pilot operated fixed displacement motor, planetary gear reduction unit, spring applied hydraulic released 360 degree multi-plate park brake, audio swing alarm, right side viewing camera, two position positive house lock, and free swing mode
COUNTERWEIGHT 28,800 lbs. (13.2mt) of total counterweight consisting of three, hydraulically removable counterweights with capacities for 0 lbs. (0mt), 9,600 lbs. (4.4mt), 19,200 lbs. (8.8mt), and 28,800 lbs. (13.2mt) counterweight configurations.
OPERATOR'S CAB Single occupancy, 0° - 20° tilting cab of e-coated powder painted steel construction. Includes fully enclosed modular sealed compartment with pressure formed plastic trim, tinted safety glass for full vision, van style pop out operator's door, sliding right side window, vented rear window, swing up roof window with wiper and washer, front window wiper and washer, six-way adjustable seat, seat belt, fire extinguisher, Link-Belt Pulse 2.0 operating system including rated capacity limiter (anti-two block with function kick-out) with internal light bar, foot throttle, armchair dual-axis (joystick) electronic controllers, and hand held outrigger control, cab mounted work lights, AM/FM radio with Bluetooth, automatic temperature-controlled air conditioning and diesel-fired warm-water heater with defroster.
GENERAL UPPERSTRUCTURE ITEMS Left side folding guardrails, fine metering, amber strobe lights, and rear view camera.
TELESCOPIC BOOM
BOOM 40.6 to 155 ft (12.3 to 47.2m) five-section full power boom with quick reeve head machinery and selectable extension modes, five nylon head sheaves, deflector pads, auxiliary lifting sheave, mechanical boom angle indicator, wind speed indicator, and dual boom floodlights.
BOOM HOIST SYSTEM One double-acting cylinder with an integral holding valve.
WARRANTY 12-month UNLIMITED hour material and workmanship, Five (5) year structural - "See Link-NetPro for details
