30t Manitex 30100C Boom Truck Crane For Sale or Rent
Location: North Las Vegas, NV 89032, USAManitex Authorized Dealer
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
Status | For Sale or Rent |
---|---|
Year | 2018 |
Manufacturer | Manitex |
Model | 30100C |
Condition | New |
Stock Unit # | 72561 |
Ton (USt) | 30.00 |
Main Boom Length | 100' |
Jib Extension Length | 26' - 46' |
Base Weight (GVW) | 60000 |
Truck Chassis Make | Freightliner |
Engine | Detroit DD13 12.8L Diesel |
Horse Power/kW | 410 |
Category | Boom Trucks |
Sub Category | Stand Up |
Show More | |
Hide |
DESCRIPTION
Standard features:
2 speed hoist with grooved drum, 7 ton hook and ball, 3-load sheave quick reeve boom head, 100’ four section telescopic boom A-Frame, Externally wired anti-two block with lockout, Boom hoist cylinder, System pressure gauge, 372° Non Continuous rotation, Removable boom rest, Engine start/stop, Operators service/parts manuals, Boom length and angle indicators, Electronic Foot throttle, Signal Horn, Bubble level, Beverage Cup Holders, 335’of 9/16” rotation resistant wire rope, 70 gallon reservoir with suction strainer and ball valve, Pedestal, Swept Back Turret, rotation bearing and swing system, Dual Operator Control Stations, Can Bus Load moment indicator w/ Internal length cable-audio/visual capacity alert with shutoff, Hermetically sealed Printed Circuit Board Electrical System w/LED Circuit Status Indicators, Audible Outrigger/Stabilizer Motion Alarm, A-Frame Link Type Front Outriggers (22’4” Spread Width), 3-section Hydraulic Pump-Counterclockwise Rotation is standard, Outrigger monitoring system.
Additional Options:
• 2 Piece 26’ – 46’ Jib (G/RS)
• 21’ HH Steel Bed x 102”
• Chassis Mounted Reservoir
• 15 ton 1-Sheave Quick Reeve Block
• Front center stabilizer
• Control valve for operation of single stabilizer, required w/FBS
• Aluminum tool box (48” L x 24” W x 24” H) Chassis Mount
MOUNTED ON 2018 FREIGHTLINER 114SD
Mounted on a 2018 Freightliner 114SD tractor chassis with a Detroit DD13 12.8L 410 HP diesel engine, RTO-14908LL Eaton Fuller Transmission, Detroit DA-F-20.0-5 20,000 lb. front suspension, MT-40-14XP 40,000 lb. Tandem rear axle, Full set of Alcoa Aluminum Polished wheels, Single Aluminum 70 gallon fuel tank, Heater, Defroster and air conditioner, full instrumentation, full power windows, interior color Opal Gray, AM/FM/WB world tuner radio with auxiliary input, single air horn roof mounted, dual heated mirrors, exterior composite sunvisor, Halogen headlights, and unit is painted Elite BC white, VIN: 1FVHG3DV6JHJT0247
