2024 PM 65028 SP Knuckle Boom Crane For Sale

•    Horizontal hydraulic reach of 95’ 2”
•    Vertical hydraulic reach of approx. 109’ 1”
•    Boom Configurations: 8 Main Boom Extensions & 4  Jib Boom Extensions
•    360 Degree Continuous Crane Rotation
•    Crane Lifting Capacities in the Horizontal Position: SEE ATTACHED CAPACITY CHART
•    Main Hydraulic out and down Outrigger max. spread 28’ 7”
•    All hydraulic
•    Manual emergency control levers
•    Danfoss Control Valves
•    Scanreco Radio Remote Control System
•    Crane Based hydraulic reservoir capacity 66 gal
•    Hydraulic oil cooler
•    Height of crane above mounting surface in folded position - 105”
•    Type 5.0SI-10.5T Rear supplementary Outrigger max. span - 16’ 5” (installed behind tandem)
•    Mount Bolt Kit and Swivel Load Hook
•    Operators and Service Manuals
•    Crane painted standard PM Blue RAL 5002
•    Platform steel body to be installed with sub-frame to extend from behind cab of chassis under crane to end of platform body
•    GSEE SD 22’ x 96” Platform Body w/48” Headboard to include 36” tool box with 6 sliding ratchets and straps
● Detroit Diesel  DD-13 470 HP Diesel Engine
● Allison 4500 RDS Automatic 6 Speed Transmission
● 20,000 lb. Capacity Front Axle
● 46,000 lb. Capacity Tandem Axle
● 20,000 lb. Steerable Pusher w/tires and white disc wheels
● 267” Wheel Base
