2020 Manitex TC700 70-Ton Boom Truck Crane For Sale or Rent
Location: Cropac Equipment Inc., Sumas Industrial Park, North Parallel Road, Abbotsford, BC, CanadaThis equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
This equipment has SOLD
Status | For Sale or Rent |
---|---|
Year | 2020 |
Manufacturer | Manitex |
Model | TC700 |
Condition | New |
Hours | 199 |
Serial Number | 272775 |
Ton (USt) | 70.00 |
Main Boom Length | 38.5' - 115' |
Jib Extension Length | 31' - 53' |
Base Weight (GVW) | 100,008 lbs. |
Transmission Type | Manual |
Miles/KM | 12,000 Kilometers |
Truck Chassis Make | Kenworth T880 |
Engine | Paccar MX-13 |
Horse Power/kW | 510 |
Category | Boom Trucks |
Sub Category | Swing Seat |
Show More | |
Hide |
DESCRIPTION
4 Section 38.5' - 115' Telescopic Boom
● Two-piece lattice swing away
● 7 Ton Top swivel ball with hook and latch
● 3 Sheave hook Block
● 16,500 lbs Counterweight Total - Removable
● 662', 5/8" Dia. Rotation Resistant Wire Rope
● Auxiliary Winch Dynamic
● 4X-Pattern Out-And-down outriggers
● Handheld Radio Operated Controller for Outriggers & Remote Winch Control
● Removable Aluminum Pads Stored at Outrigger
● Two position Outriggers Full and Retracted Spread Capacities
● 2-speed Hoist w/ Grooved Drum, Roller Tensioner, Piston Motor
● Wire Rope for Auxiliary Winch - 500'
● 6-Load Sheave Quick Reeve Boom Head
● External Hard Wire Anti-Two Block
● Continuous Rotation with Cable Operated Swing Lock
● Reclining Cab w/Dual Axis Joystick Controls & Folding Step Access
● Air Conditioned and Electrically Heated Operator's Cabin
● Boom extend/retract - slider thumb-switch
● Foot Operated and Thumb Slide Activated Throttle
● Hydraulic Rotation Drum Indicator
● Remote Counterweight Removal Controls
● Variable Displacement Load Sense Hydraulics
● 1-Section Gear Pump for Swing Function
● 220-Gal Hydraulic Reservoir w/Suction Strainer & Ball Valve
● Load Moment Indicator - Full Visual/Audio Capacity Alert w/Shutoff
● Diamond Plated Aluminum Decking
2019 - KENWORTH T880 - TANDEM TRIDEM
● 40,000lb front tandem axle
● 69,000lb rear tri-drive axle with air suspension, wide track
● Paccar MX-13 510 HP
● Fuller RTLO 18918B 18 Speed Transmission
● Front tires 445 65R22.5, Rear tire Z 12 FR22.5
● 120 US gallon fuel tank
● Heating/Air Conditioning with defroster
● AM/FM//WB/USB and Bluetooth radio
