2018 MANITEX 26101C For Sale
Location: Santa Ana, CA 92703, United StatesManitex Authorized Dealer
This equipment has SOLD
DESCRIPTION
NEW MANITEX 26101C
2 speed hoist with grooved drum, 7 ton hook and ball, 3-load sheave
Standard features:reeve boom head, 101’ four section telescopic boom, Externally wired anti-two block, Boom hoist cylinder, System pressure gauge, 372° Non Continuous rotation, Removable boom rest, Engine start/stop, Operators service/parts manuals, Boom length and angle indicators, Function Overload Shutoff, Electronic throttle, Bubble Level, 300’of 9/16” rotation resistant wire rope, 70 gallon reservoir Bed Mounted w/suction strainer and ball valve, Pedestal, Turret, rotation bearing and swing system, Dual Operator Control Stations, Load moment indicator-audio/visual alert w/shutoff, Audible Outrigger/Stabilizer Motion Alarm, A-Frame outriggers (21’6” Spread Width), A-Frame Rear Stabilizers, 3-section Hydraulic Pump-Counterclockwise is standard, Sub frame for 22’ Bed, Signal Horn, Outrigger monitoring system for verification only. quick
• Control valve for operation of
• Front center stabilizer
• Chassis Mounted Hydraulic Reservoir in lieu of standard
• 15 ton 1-Sheave Quick Reeve Block for 2-3 part line
• 22’ Steel Bed with 1/8” thick Steel Thread Plate
• 1 Piece 29’ Jib (101’) (G/RS)
Additional Options: stabilizer, required w/FBS
• Aluminum tool box (48” L x 24” W x 24” H) Chassis Mounted
MOUNTED ON 2018 FREIGHTLINER 108SD
Mounted on a 2018 Freightliner 108SD tractor chassis with a Cummins L9 350 HP diesel engine, Eaton Fuller RTO-14908LL Transmission, Detroit DA-F-20.0-5 22,000 lb. front suspension, MT-40-14X 46,000 lb. rear tandem axle, Full set of Alcoa Aluminum Polished wheels, Single Aluminum 50 gallon fuel tank, Heater, Defroster and air conditioner, full instrumentation, full power windows, interior color Opal Gray, AM/FM/WB World Tuner Radio with USB and Bluetooth and auxiliary inputs radio, single air horn, dual heated mirrors, exterior compositesunvisor, Halogen headlights, and unit is painted White Elite BC.single
